Description

Overview

The CLF035-S101 is a 12mm 12MP C-mount lens designed for 1/1.8" image sensors — the telephoto-class option in our replaceable lens family, delivering a 38.16° diagonal field of view with very low TV distortion of just -0.67%. With manual iris (F2.8-F16) and manual focus (0.05m~∞), it gives full exposure and depth control for automotive, machine vision and robotics applications.

It pairs directly with EyeCloud AI GMSL cameras such as the GMSL2 C-Mount Camera, complementing the wider FOV60 option for long-range viewing scenarios.

Key Features

12MP Resolution: High center MTF for sharp, detailed imaging on 1/1.8" sensors.
Telephoto FOV: 38.16° diagonal / 31.76° horizontal / 21.17° vertical field of view.
Very Low Distortion: TV distortion of only -0.67% for accurate imaging.
Manual Iris & Focus: F2.8-F16 aperture and 0.05m~∞ focus range for full exposure control.
C-Mount Mounting: Directly compatible with EyeCloud AI GMSL cameras.

Specifications

Parameter	Value
Model	CLF035-S101
Focal Length	12mm
Resolution (Center MTF)	12MP
Max. Aperture	F2.8-F16
Sensor Size	1/1.8"
FOV Diagonal	38.16°
FOV Horizontal	31.76°
FOV Vertical	21.17°
TV Distortion	-0.67%
CRA (Chief Ray Angle)	15.7°
Focus Range	0.05m ~ ∞
Iris	Manual
Focus	Manual
